ProCharger 2024-2026 Ford F-150 5.0L V8 Stage 3 Intercooled Supercharger System
1EC511-SCI
- In stock, ready to ship
- Backordered, shipping soon
- Orders Over $750 Ship Free!
Bolt-On ProCharger Power, Backed by TCcustoms
Stage 3 gives your 2024-2026 F-150 5.0L the strongest foundation ProCharger builds for this truck. It carries the same 75 to 80 percent power gain as Stage 2 and adds a dedicated 8-rib belt drive plus a 1600 plus HP air-to-air race intercooler, so the hardware is ready when you want more.
Key Specs
- 75 to 80 percent or more horsepower on 91/93 octane (stock engine and exhaust)
- 12 psi of boost
- P-1X ProCharger head unit, satin finish standard
- Dedicated 8-rib belt drive standard
- 1600 plus HP air-to-air race intercooler
- Fuel system upgrade components included
- Complete system with PCM tuning included
- Typical install time 8 to 9 hours
What Is in the Box
- P-1X centrifugal supercharger (satin, black, or polished finish)
- Dedicated 8-rib drive system
- 1600 plus HP air-to-air race intercooler and tubing
- Fuel system upgrade components
- PCM tuning
- All hardware and instructions
Options and Upgrades
Use the option pickers above to choose your configuration. More upgrades are available when you order, just call us or add a note at checkout:
- Crank support for very high horsepower builds, add $675 in satin or $950 in black or polished
- Bullet blow-off valve, add $125, or race valve in red or black, add $295
- Helical gear set, add $110
- Black bracket finish, add $225, or polished, add $325
- Black intercooler finish, add $195
Fitment
2024 Ford F-150 with the 5.0L V8 Coyote engine
2025 Ford F-150 with the 5.0L V8 Coyote engine
2026 Ford F-150 with the 5.0L V8 Coyote engine
California note: ProCharger does not currently list a CARB Executive Order for this application, so we cannot sell this system for street use in California. Call us if you are in an emissions regulated state and we will walk you through your options.
Complete ProCharger systems like this one are eligible for an optional powertrain warranty through ProCharger's partner, Pinnacle Protect. Ask us for current terms when you order.
Common Questions
What does Stage 3 add over Stage 2?
A dedicated 8-rib belt drive and the 1600 plus HP race intercooler. If your plans include more boost later, start here.
Is there a Pro Power Onboard version of Stage 3?
ProCharger currently offers the Pro Power configuration on Stage 1 and Stage 2 systems and the Stage 2 tuner kit. Call us if your truck has Pro Power and you want Stage 3 level hardware.
Can TCcustoms install it?
Yes. We install ProCharger systems at our Bessemer and Pell City shops. Plan on 8 to 9 hours of install time.
Why Buy From TCcustoms
TCcustoms is a ProCharger dealer with full installation shops at both of our Alabama locations, Bessemer and Pell City. We install what we sell, we ship nationwide, and customers drive and ship vehicles to us from all over the country for supercharger installs and custom builds. Call us before you order and a real builder will help you spec the right setup the first time.
Prices shown are ProCharger MSRP. Part number 1EC511 series, made in the USA by ProCharger in Lenexa, Kansas.
