Camburg KINETIK Series Billet Uniball Upper Control Arm Kit (Gold) - 2017-2024 Ford F-150 Raptor / Raptor R

The Camburg KINETIK Series billet uniball front upper control arm kit in gold (part number CAM-110233-GLD) is a CNC-machined 6061 billet aluminum upper control arm set for the 2017-2024 Ford F-150 Raptor and 2023-2024 Ford F-150 Raptor R. Made by Camburg Engineering.

Overview

Our Camburg KINETIK Series billet upper control arms are designed specifically for the 2017-24 Gen2 and Gen3 Ford Raptors, including the 2019+ models with FOX Live Valve electronic suspension. These arms have undergone extensive CAD designing and machining to meet our high standards. They are CNC machined in-house from aerospace quality 6061 billet aluminum, bead blasted, Type II anodized gold, and feature our Camburg logo laser etched. The arms utilize a larger FK 1.25" uniball with a PTFE liner for increased strength and mis-alignment, allowing for maximum wheel travel. Made in the USA, these arms are superior to cheaper imports. The uniball is adapted to the spindle/knuckle using model specific spacers machined from heat-treated stainless steel, ensuring a precise fit without the need for drilling or modifications. The 1.25" uniball allows for a larger and stronger 9/16" 12 point bolt with a low profile press-on uniball cap to resist the elements. Additional camber and caster adjustment is possible with the use of larger and stronger FK 7/8" chromoly heim joints, which also eliminate flexing/deflection under hard use and braking without binding. AN/Mil-spec hardware, including a single pinch bolt and secondary jam nut, ensures secure attachment of the heim joint. For 2019+ models with a position sensor incorporated into the FOX electronic suspension, stainless brackets are provided to attach to our arms for the sensor linkage, along with a drill template for proper positioning. The installation process is simple. The new V2 design of these control arms increases usable wheel travel, corrects camber and caster, and eliminates weak factory ball-joints. All necessary hardware is included for installation, and the arms are designed for 1-3" of lift. When using the factory OEM 17" wheels, a 1/4" - 3/8" wheel spacer may be required when running larger tires than stock. We recommend zero offset wheels (5.00" backspacing) when running larger tires than stock.

• NEW V2 design
• Increases usable wheel travel
• Corrects camber and caster
• Eliminates weak factory ball-joints
• CNC machined 6061 billet aluminum
• CAD/CAM engineered
• FK 7/8" heim joints for adjustable camber and caster
• FK 1.25" PTFE-lined uniballs pre-installed
• Anodized and laser etched
• All necessary hardware included and ready to install
• Made in the USA
• Designed for 1-3" of lift
• Fits Raptor and Raptor R models with factory wheels & tires (35-37")

What's included

• Camburg Billet Upper Arms
• Press-on Uniball Caps
• FK 7/8" Heim Joints
• FK 1.25" Uniballs
• Heat-treated stainless steel uniball and heim spacers
• Grade 8 and AN Aircraft Hardware
• Stainless position sensor brackets and drill fixture/template

Fitment details

2017-2024 Ford F-150 Raptor | Raptor R (Make: Ford | Model: Raptor). We recommend wheels with 4.75-5.00" backspacing when running aftermarket 35-37" tires. Fits Raptor and Raptor R models with factory wheels & tires (35-37").

Fitment

• Vehicle: Ford F-150
• Model(s): Raptor, Raptor R
• Years: Raptor 2017-2024; Raptor R 2023-2024
• Engine: 3.5L EcoBoost twin-turbo V6 (Raptor) / 5.2L supercharged V8 (Raptor R)

Disclosures

ATTENTION STATE OF CALIFORNIA CONSUMERS. WARNING: Cancer and reproductive harm - www.p65warnings.ca.gov

Installation

Bolt-on installation with no drilling or modifications needed. Designed for 1-3" of lift.

TCcustoms installs this at both our Bessemer and Pell City, Alabama shops. Contact us to schedule installation, or we can ship your part anywhere in the country.

Fits: 2017-2024 F-150 Raptor, 2023-2024 F-150 Raptor R
